Discover - Implementing SSO with Login ...

Introduction

This is an overview guide on how to implement SSO (Single-Sign-On) with Claromentis and DUO

📙 Google Documentation: SAML SSO configuration using Google Workspace

Step 1: Configure Google Workspace for single sign-on (SSO)

2. In Google Workspace Admin Console, go to Apps > Web and mobile apps.

3. Select Add Custom SAML app.

4. In the App name field, add a name that will help you identify this SAML app for example:

Claromentis Intranet SSO

5. Click Continue.

6. Download IdP metadata which is to be uploaded to Claromentis

7. Service Provider Details

ACS URL: get this from Single SignOn URL field in Claromentis example:

https://{your-system-url}/custom/loginhandler/simplesaml/www/module.php/saml/sp/saml2-acs.php/claromentis

Entity ID: get Entity ID under IDP Configuration in Claromentis

Start URL (optional) : this is typically is your system URL

Name ID format: UNSPECIFIED

NAME ID : Basic Information > Primary email

8. Attributes Mapping

Google doesn't have a Username and uses Primary email which needs to be mapped as Username in Claromentis

Step 2: Configure SSO in Claromentis

Navigate to Admin → Custom Login handler → SSO Configuration

1. Select Identity Provider "Google"

2. Upload Federation Metadata XML (you will need XML from Google Workspace containing IdP metadata)

3. Populate Security Configuration

4. IDP Identifier: this should be populated from the XML

5. Entity ID you will need to copy this to Google Workspace SSO Configuration

7. Name ID Policy: Unspecified

6. Save Options

Navigate back to Google Workspace and click on Test SAML login
