Setting up Workflow for Documents

What's possible within Documents Workflow?


Within the Documents application, it is possible to create workflow rules to setup any of the following:

  • Create states for documents, such as Awaiting Approval and Approved.
  • Set the transitions between states to be manual, automatic based on one or multiple approvals, or automatic based on a time having elapsed or date having been reached.
  • Specify exactly who should have to approve documents
  • Request feedback from approving users as the documents moves through the workflow
  • Move the document to a specified folder as the document moves between states
  • Specify 'workflow managers'. Documents can be set to Read-Only except for these users.
  • Send notifications of changes to Workflow managers and document owners.

An unlimited number of workflows can be created, and workflows are applied to folders so that any newly uploaded items must go through your specified workflow process.



Example Workflow 1: Group approval


Scenario: I want any documents within my Support and Maintenance Documents folder to:

  1. Require approval from all three heads of department

  2. Be visible but read only to users while it's awaiting approval

  3. Start on a state of Unapproved and move to a state of Approved

Steps

Head to Admin > Workflow. If you don't see Workflow, you will need to ensure you are set as an administrator.

Click Add New Category. Create a category called Support and assign 'create workflow' permissions to a user group such as Support Managers.

Save. Now click Add New Workflow. Add it into the category you have just created, and call it All 3 heads to approve.

Now create the two states of Unapproved and Approved, picking colours to match such as orange and green.

On the Unapproved line of the table containing the two states, click the pencil on the right to edit the action.

Around the middle of the page, tick the box 'Make document read only'

Under 'transition', set the next state to Approved, and set transition type to "On All Approve". Click 'save transitions'.

You will see a link has now appeared - 'View/Edit responsible persons'. Click it, and add in the users who will need to approve, such as a user group called Heads of Department.

Save to close the window, and click add/update to save the changes you have made to the workflow.

Now head to Admin > Documents > Manage Documents List and find the folder we wish to apply this workflow to, Support and Maintenance Documents. Edit its properties.

Select the workflow All 3 heads to approve, and click Update Folder Properties.



Now, any documents added to that folder will be read only until they're approved by all of the heads of department.



Example Workflow 2: Moving old documents


Scenario: I want any documents within my Recent Sales Documents folder to automatically move themselves into my Old Sales Documents folder after six months

Steps

Head to Admin > Workflow. If you don't see Workflow, you will need to ensure you are set as an administrator.

Click Add New Category. Create a category called Sales and assign 'create workflow' permissions to a user group such as Sales Managers.

Save. Now click Add New Workflow. Add it into the category you have just created, and call it Move out documents older than 6 months

Now create the two states of Recent Document and Older Documentpicking colours to match such as green and grey.

On the Recent Document line of the table containing the two states, click the pencil on the right to edit the action.

Under 'transition', set the next state to Older Document, and set transition type to "On Time Elapse", and set to 180 days.

Click add/update to save the changes you have made to the workflow.

On the Older Document line of the table containing the two states, click the pencil on the right to edit the action.

Set the Action to be 'Move to a folder'. Click 'choose folder' and select the Old Sales Documents folder.

Click add/update to save the changes you have made to the workflow. On the next screen click save.

Now head to Admin > Documents > Manage Documents List and find the folder we wish to apply this workflow to, Recent Sales  Documents. Edit its properties.

Select the workflow Move out documents older than 6 months, and click Update Folder Properties.



Screenshots



A screenshot of the list of transition types



If Manual is the transition type, the approving workflow users will see this on a document.



If Auto - On All Approve is the chosen transition type, the approving users are shown a table of who has and is yet to approve.



Within the front end of the Documents application, users can click the button highlighted here to see all documents that are currently in the middle of a Workflow process.
